Meade Power Supply Units
SKU: 606001.
The LXPS Rechargeable Portable Power Supply easily powers your telescope and electronic devices while in the field. Connect your equipment using the two 12V cigarette lighter ports,
two USB ports, or through the positive/negative terminals on the back. The LXPS includes a built-in circuit breaker and fused circuit to protect your valuable equipment.
With USA and international type AC adapter plugs, you’ll be able to recharge the LXPS both in the field and overseas.
The Meade LXPS 7 also includes an adjustable super bright 30 LED spotlight and white flashlight with red filter attachment, perfect for setting up and tearing down in the dark.
The LXPS is great for emergency situations like jump starting your car battery. With 7-amp hours, the LXPS 7 is a key essential to compliment any observing session.
SKU: 606002.
With Meade’s new LXPS 17 Rechargeable Portable Power Supply you can easily power your telescope and electronic devices in the field. 12V, with a massive
17 amp-hour capacity. Connect your equipment using the two included 12V cigarette lighter ports, two USB ports, or through the positive/negative terminals
on the back. The LXPS includes a built-in circuit breaker and fused circuit to protect your valuable equipment. Includes both USA and international type
AC adapter plugs so you’ll be able to recharge the LXPS anywhere you travel.
The Meade LXPS also includes an adjustable super bright 30 LED spotlight and white flashlight with red filter attachment, perfect for setting up and tearing
down in the dark. Additionally, the LXPS 17 includes an AM/FM radio, siren, and tethered detachable light. The LXPS can also be used for emergency situations
like jump starting your car battery. With 17-amp hours, the LXPS 17 is the must-have accessory for star parties, long observing sessions and the dedicated astronomer.
LXPS 7 Power Supply | LXPS 17 Power Supply | |
Opticstar Retail Price | discontinued | £125.00 |
Product Code | 606001 | 606002 |
Battery Type | Sealed Lead Acid Battery | Sealed Lead Acid Battery |
Cell Capacity | 7-amp hour | 17-amp hour |
Contents Included | 1. Two(2) DC Cigarette lighter adapters with plug 2. One(1) Plug adapter (OD 5.5mm, ID 2.0mm) to (OD 5.5mm, ID 2.5mm) 3. One(1) AC adapter 4. One(1) EU international adapter plug 5. One(1) US international adapter plug 6. One(1) UK international adapter plug 7. One(1) Red filter cap for built in flashlight(pre-installed) 8. One(1) Carry strap (pre-installed) 9. One(1) LXPS 7 Instructional manual | 1. Two(2) DC Cigarette lighter adapters with plugs 2. One(1) Plug adapter (OD 5.5mm, ID 2.0mm) to (OD 5.5mm, ID 2.5mm) 3. One(1) AC adapter 4. One(1) EU international adapter plug 5. One(1) US international adapter plug 6. One(1) UK international adapter plug 7. One(1) LXPS 17 Instructional manual |
Features | 1. Two(2) DC Cigarette lighter adapters with plug 2. One(1) Plug adapter (OD 5.5mm, ID 2.0mm) to (OD 5.5mm, ID 2.5mm) 3. One(1) AC adapter 4. One(1) EU international adapter plug 5. One(1) US international adapter plug 6. One(1) UK international adapter plug 7. One(1) Red filter cap for built in flashlight(pre-installed) 8. One(1) Carry strap (pre-installed) 9. One(1) LXPS 7 Instructional manual | 1. Two 12V/10A output cigarette lighter ports with circuit breaker 2. Two built-in USB ports (5V/1.5A) with 2 amp fuse 3. Thirty white LED spotlight with adjustable housing. 4. Removable red filtered flashlight with cord and magnetic base 5. AM/FM Radio with Siren 6. Positive & negative terminals 7. Battery status indicator light 8. AC adapter with international plugs(EU,US,UK) for recharging power adapter 9. Two Cigarette lighter adapters with plug 10. Meade Adapter plug |
Operating Temperature | 0°C to 30°C (32°F to 86°F) | 0°C to 30°C (32°F to 86°F) |
Product Dimensions | 288mm H x 236mm W x 132mm D (11.3" x 9.3" x 5.2") | 355mm H x 345mm W x 132mm D (13.9" x 13.6" x 5.2") |
Product Weight | 3.8 kg (8.4 lbs) | 7 kg (15.4 lbs) |
Storage Lifetime | • At temperatures less than 10°C: should be charged at least once every 180 days. • At temperatures from 10 °C to 27 °C: should be charged at least once every 90 days. • At temperatures from 27 °C to 40 °C: should be charged at least once every 45 days. | • At temperatures less than 10 °C: should be charged at least once every 180 days. • At temperatures from 10 °C to 27 °C: should be charged at least once every 90 days. • At temperatures from 27 °C to 40 °C: should be charged at least once every 45 days. |
Voltage | 12 Volt Rechargeable | 12 Volt Rechargeable |
Warranty | 1 year | 1 year |
