Meade ACF f/8 16-inch optical tube assembly (OTA)

Fast Advanced Coma-Free (ACF™) optical system for crisp, pinpoint imaging.

  • Advanced Coma-Free (ACF™) optics
  • Ultra High Transmission (UHTC™) coatings
  • Diffraction limited optics
  • Aperture: 406mm (16")
  • Focal Length: 3,251mm (f/8)
  • Oversized low-expansion primary mirror
  • Mirror-Lock for increased image stability
  • Dual speed 7:1 focuser
  • Losmandy-style dovetail
  • UK warranty
Meade ACF f/8 16-inch OTA
  • Product code: 1608-80-01
  • Availability: In stock
  • Despatch: 2 business days
  • Retail Price: £ 10999.00
Shipping rates
England & Wales
£ 30.00
Scotland Central & South
£ 30.00
Scotland North
£ 350.00
Northern Ireland
£ 350.00

Description

Building on Meade’s award-winning Advanced Coma-Free™ (ACF™) optics, the 14" optical tube assembly (OTA) employs a fast f/8 optical system with high-contrast baffling that insures crisp, pinpoint imaging to the very edge of the field. Features an internal zero image shift Crayford-style focusing system with a two-speed 7:1 reduction control that provides smooth, precise focusing at any magnification.

Also features Meade's Ultra-High Transmission Coatings (UHTC) for maximum brightness and contrast, an oversized low-expansion primary mirror for extra aperture and to prevent thermal expansion of the mirror, and diffraction-limited optics.

Meade 16" f/8 ACF Optical Tube Assembly #1608-80-01 includes a precision machined Losmandy-style dovetail rail mated to the tube with wide-stance radius blocks for rock-steady mounting, and front and rear dust covers. Focal length 3251mm. OTA weight is 32 kg (70 lbs).


U.K. WARRANTY

ADVANCED

OPTICS

PHOTOGRAPHY

ASTRONOMY
▼ read more ▼

Mirror lock

All ACF f/8 models feature a primary mirror locking mechanism, which effectively prevents movement of the primary mirror during long exposure astrophotography or observing. Turn the lock knob located just above the telescope’s main focus knob and the progressive-tension primary lock completely cancels any residual image shift due to mirror movement during visual, photographic, or imaging applications.

Carries full one year UK warranty by Opticstar Ltd on behalf of Meade Instruments Corp.

Meade ACF f/8 optics.
▲ read less ▲
▼ show specification ▼
Meade ACF f/8 16-inch OTA
Attribute Specification
Meade Product Code / sku 1608-80-01
Universal Product Code (UPC) 709942998047
Warranty 1 year UK warranty by Opticstar Ltd on behalf of Meade Instruments USA
Series LX850
Experience Level Advanced
Clear Aperture 406mm (16-inch)
Focal Length 3,251mm
Focal Ratio f/8
Optical Design ACF™ (Advanced Coma-Free)
Optical Coatings UHTC™ (Ultra High Transmission Coatings)
Primary Mirror Oversized Low-Expansion Borosilicate Primary Mirror
Correcting Plate/Lens Schott Borofloat Glass Corrector Plate
Resolving Power (Dawes' Limit) 0.285 arc-seconds
Diffraction-Limited Optics Yes
Oversized Primary Mirror Yes
Mirror Lock Yes
Focuser Internal Crayford-style, zero image-shift, dual speed 7:1 focuser
Dovetail Losmandy®-style with ultra stable radius blocks
Eyepiece Optional
Diagonal Optional
Viewfinder Optional
Optical Tube Assembly (OTA) Weight 32 kg (70 lbs)
Transit Weight 57 kg
Transit Dimensions 108cm x 100cm x 70cm
▲ hide specification ▲
